Description
| ELECTRICAL SPECIFICATIONS | MECHANICAL SPECIFICATIONS | ||
| Nominal Voltage | 12.8 V | Dimensions (L x W x H) | 12.95 x 6.77 x 8.9” 329 x 172 x 223 mm |
| Nominal Capacity | 100 Ah | Weight | 27.9 lbs (12.64 kg) |
| Capacity @ 25A | 240 min | Terminal Type | M8 x 1.25 |
| Energy | 1280 Wh | Terminal Torque | 80 – 100 in-lbs (9 – 11 N-m) |
| Resistance | ≤30 mΩ @ 50% SOC | Case Material | ABS |
| Efficiency | 99% | Enclosure Protection | IP66 |
| Self Discharge | <3% per Month | Cell Type – Chemistry | Cylindrical – LiFePO4 |
| Maximum Modules in Series | 1 (Single-Use) | ||
| DISCHARGE SPECIFICATIONS | CHARGE SPECIFICATIONS | ||
| Maximum Continuous Discharge Current | 100 A | Recommended Charge Current | 5 A – 50 A |
| Peak Discharge Current | 200 A (7.5 s ±2.5 s) | Maximum Charge Current | 100 A |
| BMS Discharge Current Cut-Off | 280 A ±50 A (32 ±10 ms) | Recommended Charge Voltage | 14.2 V – 14.6 V |
| Recommended Low Voltage Disconnect | 11 V | BMS Charge Voltage Cut-Off | 15.4 V (3.85 ±0.025 vpc) (1000 ±200 ms) |
| BMS Discharge Voltage Cut-Off | 9.2 V (2.3 ±0.08 vpc) (4.7 ±1 s) | Reconnect Voltage | 14.6 V (3.65 ±0.05 vpc) |
| Reconnect Voltage | 10 V (2.5 ±0.1 vpc) | Balancing Voltage | 14.4 V (3.6 ±0.025 vpc) |
| Short Circuit Protection | 200-600 μs | Recommended Charge Current | 5 A – 50 A |
| Maximum Charge Current | 100 A | ||
| TEMPERATURE SPECIFICATIONS | HEATING ELEMENT SPECIFICATIONS | ||
| Discharge Temperature | -4 to 140 ºF (-20 to 60 ºC) | Heating Temperature Range | -4 to 41 ºF (-20 to 5 ºC) |
| Charge Temperature | -4 to 113 ºF (-20 to 45 ºC) | Heating Time | Approximately 1 hr @ 10 A |
| Storage Temperature | 23 to 95 ºF (-5 to 35 ºC) | ||
| BMS High Temperature Cut-Off – Discharge | 185 ºF (85 ºC) | ||
| BMS High Temperature Cut-Off – Charge | 140 ºF (60 ºC) | ||
| Reconnect Temperature | 122 ºF (50 ºC) | ||
| COMPLAINCE SPECIFICATIONS | |
| Certifications | CE (battery) |
| UL1642 & IEC62133 (cells) | |
| Shipping Classification | UN 3480, CLASS 9 |
