Description
| ELECTRICAL SPECIFICATIONS | MECHANICAL SPECIFICATIONS | ||||
| Nominal Voltage | 51.2 V | Dimensions (L x W x H) | 32.8 x 11.2 x 10.0” | ||
| Nominal Capacity | 100 Ah | 832.4 x 285 x 255 mm | |||
| Capacity @ 25A | 240 min | Weight | 62 lbs (136.7 kg) | ||
| Energy | 5120 Wh | Terminal Type | M8 x 1.25 | ||
| Resistance | 50 mΩ @ 50% SOC | Terminal Torque | 80 – 100 in-lbs (9 – 11 N-m) | ||
| Efficiency | 99% | Case Material | Steel Case | ||
| Self Discharge | <3% per Month | Enclosure Protection | IP65 | ||
| Maximum Modules in Series | 1 (Single Use) | Cell Type | Cylindrical | ||
| Battery Chemistry | LiFePO4 | ||||
| DISCHARGE SPECIFICATIONS | CHARGE SPECIFICATIONS | ||
| Maximum Continuous Discharge Current | 200 A | Recommended Charge Current | 5 A – 50 A |
| Peak Discharge Current | 250 A (4 s ±1 s) | Maximum Charge Current | 100 A |
| BMS Discharge Current Cut-Off | 300 A (5 s) | Charge Current 32ºF to 14ºF (0 to -10 ºC) | ≤0.1 C |
| Recommended Low Voltage Disconnect | 44 V | Charge Current -4ºF to 14ºF (-20 to -10 ºC) | ≤0.05 C |
| BMS Discharge Voltage Cut-Off | 40 V (2.5 vpc) | Recommended Charge Voltage | 56.8 V – 58.4 V |
| Reconnect Voltage | 40.5 V (2.53 vpc) | BMS Charge Voltage Cut-Off | 60.8 V (3.8 ±0.025 vpc) |
| Short Circuit Protection | 5% | (1.0 ±0.3 s) | |
| Reconnect Voltage | 60.8 V (3.9 vpc) | ||
| Balancing Voltage | 60.3 V (3.87 vpc) | ||
| TEMPERATURE SPECIFICATIONS | COMPLIANCE SPECIFICATIONS | ||
| Discharge Temperature | -4 to 131 ºF (-20 to 55 ºC) | Certifications | CE (battery) |
| Charge Temperature* | -4 to 131 ºF (-20 to 55 ºC) | UL1642 & IEC62133 (cells) | |
| Storage Temperature | 23 to 95 ºF (-5 to 35 ºC) | Shipping Classification | UN 3480, CLASS 9 |
| BMS High Temperature Cut-Off | 149 ºF (65 ºC) | ||
| Reconnect Temperature | 145 ºF (63 ºC) | ||
| *Refer to charge currents below 0°C (32°F) | |||
