Description
MECHANICAL SPECIFICATIONS
| Industry Reference | ||
| Length A (in/mm) | 5.9 | 151 |
| Width B (in/mm) | 2.6 | 65 |
| Height C (in/mm) | 3.7 | 95 |
| Total Height D (in/mm) | 4 | 101 |
| Weight (lbs/kgs) | 5.39 | 2.45 |
| Terminal * | F2 | |
| Technology | AGM, VRLA | |
NOTE 1: Dimensions have a ±2 mm (0.08 in) tolerance. Weights may vary.
NOTE 2: Refer to terminal guide on website for torque values.
ELECTRICAL SPECIFICATIONS
| Voltage (V) | 12 | |
| Internal Resistance (mΩ) | 25 | |
| Short Circuit (A) (20°C / 68°F) | 400 | |
| Self-Discharge (20°C / 68°F) | 2-3% per month | |
| Charge Temperature | Min: -10°C (14°F) | Max: 50°C (122°F) | |
| Discharge Temperature | Min: -40°C (-40°F) | Max: 50°C (122°F) | |
| Storage Temperature | -20°C (-4°F) to 60°C (140°F) | |
NOTE 3:Â Extra considerations must be given when designing systems for use at maximum temperatures.
NOTE 4:Â Internal Resistance is approximate.
PERFORMANCE SPECIFICATIONS
| Amp Hours (AH) | |||
|---|---|---|---|
| 1 HR | 5 HR | 10 HR | 20 HR |
| 5.8 | 7.7 | 8.5 | 9 |
1HR @1.60VPC, 5HR @1.75VPC; 10 HR@ 1.80VPC; 20 HR @1.80VPC. All at 30°C/86°F
| Discharge Constant Current (Amperes) @ 25°C / 77°F | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| VPC/Time | 5 MIN | 10 MIN | 15 MIN | 30 MIN | 1 HR | 3 HR | 5 HR | 10 HR | 20 HR |
| 1.60 VPC | 32.50 | 24.00 | 16.80 | 9.90 | 5.80 | 2.33 | 1.60 | 0.90 | 0.48 |
| 1.65 VPC | 31.70 | 23.50 | 16.30 | 9.79 | 5.75 | 2.29 | 1.56 | 0.89 | 0.47 |
| 1.70 VPC | 30.50 | 22.70 | 15.80 | 9.36 | 5.71 | 2.25 | 1.55 | 0.88 | 0.47 |
| 1.75 VPC | 29.80 | 21.80 | 14.80 | 8.91 | 5.66 | 2.20 | 1.54 | 0.87 | 0.46 |
| 1.80 VPC | 29.20 | 21.00 | 13.90 | 8.45 | 5.51 | 2.14 | 1.53 | 0.85 | 0.45 |
| Discharge Constant Power (Watts) @ 25°C / 77°F | |||||||||
|---|---|---|---|---|---|---|---|---|---|
| VPC/Time | 5 MIN | 10 MIN | 15 MIN | 30 MIN | 1 HR | 3 HR | 5 HR | 10 HR | 20 HR |
| 1.60 VPC | 71.70 | 44.80 | 34.60 | 19.60 | 11.50 | 4.34 | 3.10 | ||
| 1.65 VPC | 68.30 | 44.30 | 34.10 | 19.10 | 11.20 | 4.29 | 3.04 | ||
| 1.70 VPC | 64.80 | 42.90 | 32.10 | 18.50 | 11.00 | 4.20 | 2.98 | ||
| 1.75 VPC | 61.40 | 41.10 | 31.20 | 17.60 | 10.70 | 4.08 | 2.92 | ||
| 1.80 VPC | 58.00 | 39.20 | 29.40 | 16.60 | 10.40 | 3.92 | 2.85 |
